Data Sheet
ADRF5515
Rev. 0 | Page 7 of 15
INTERFACE SCHEMATICS
GND
Figure 3. GND Interface
GND
RXOUT-CHx
VDD
Figure 4. RXOUT-CHx Interface
GND
GND
VDD1-CHx,
VDD2-CHx
CLAMP
Figure 5. VDD1-CHx, VDD2-CHx Interface
GND
GND
PD-CHAB,
BP-CHA,
BP-CHB
CLAMP
Figure 6. PD-CHAB, BP-CHx Interface
GND
GND
CLAMP
SWVDD-CHAB
Figure 7. SWCTRL-CHAB, SWVDD-CHAB Interface
