Electrical Characteristics(TA=25°C unless otherwise specified)
Part Number
Device
Marking
VRWM
(V)
VBR
(V)
IT
(mA)
VC
@1A
Vc
IR
μA
(Max)
C
(Pf)
(Typ.)
(Max)
(@A)
ESD2511CDN
N1
2.5
2.85
1
6
7.5
5
0.05
23
Characteristic Curves
Rev : 01.06.2014
2/4
www.leiditech.com
ESD2511CDN
◆
IR : < 0.05uA@25℃
◆
IR : < 0.10uA@125℃
Vc
(Max)
(@A)
13
8
