background image
GAPTEC-Electronic GmbH & Co. KG
sales@gaptec-electronic.com – www.gaptec-electronic.com
Page 2 of 3
1S7A_R – Rev. 2012-1.0
Specifications subject to change without notice.
1S7A_R Series
1W Output Dual Output - Fixed Input - Isolated & Regulated
SIP PACKAGE
Part Number
Input Voltage [V]
Output Voltage [VDC]
Current [mA, max]
Efficiency [%, max]
Package
1S7A_0505S1RP
5
5
200
66
SIP
1S7A_0509S1RP
5
9
111
70
SIP
1S7A_0512S1RP
5
12
83
71
SIP
1S7A_0515S1RP
5
15
67
73
SIP
1S7A_0524S1RP
5
24
42
68
SIP
1S7A_1205S1RP
12
5
200
67
SIP
1S7A_1209S1RP
12
9
111
72
SIP
1S7A_1212S1RP
12
12
83
70
SIP
1S7A_1215S1RP
12
15
67
74
SIP
1S7A_1224S1RP
12
24
42
68
SIP
1S7A_1505S1RP
15
5
200
67
SIP
1S7A_1509S1RP
15
9
111
71
SIP
1S7A_1515S1RP
15
15
67
72
SIP
1S7A_1524S1RP
15
24
42
68
SIP
1S7A_2405S1RP
24
5
200
68
SIP
1S7A_2409S1RP
24
9
111
68
SIP
1S7A_2412S1RP
24
12
83
73
SIP
1S7A_2415S1RP
24
15
67
75
SIP
1S7A_2424S1RP
24
24
42
68
SIP
Recommended footprint
Typical characteristics
