10YK SPECIFICATIONS

ES-0857 Rev.1 Page 3/3

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

+

–

Isolation

INPUT MONITOR

1

Low Drift

Amplifier

Output

Driver

OUTPUT 1

2

3

7

8

Voltage/

Duty Cycle

+

–

S

Z

Output

Driver

OUTPUT 2

5

6

S

Z

*Input shunt resistor incorporated for current input.

Remark 1) The section enclosed by broken line is only for 2nd output channel.

POWER

INPUT

*

Specifications are subject to change without notice.
