MODEL: ABS3

ABS3 SPECIFICATIONS

ES-9413 Rev.4 Page 2/4

https://www.m-system.co.jp/

L1 indicator: Amber LED turns on when setting the

parameter block 1.

L2 indicator: Amber LED turns on when setting the

parameter block 2.

L3 indicator: Amber LED turns on when setting the

parameter block 3.

INPUT SPECIFICATIONS

Input signal range: -10 % - +110 %

OUTPUT SPECIFICATIONS

Output available range: -10 % - +110 %

INSTALLATION

Power consumption

•AC: 4 VA at 100 V AC

5 VA at 200 V AC

6 VA at 264 V AC

•DC: ≤ 3 W

Operating temperature: -5 to +55°C (23 to 131°F)

Operating humidity: 10 to 90 %RH (non-condensing)

Mounting: Panel flush mounting

Weight: 130 g (0.29 lb)

PERFORMANCE in percentage of span

■ PV DISPLAY

Display accuracy: ±0.2 % ±1 digit of the span

Temp. coefficient: ±0.015 %/°C (±0.008 %/°F)

Line voltage effect: Included in the display accuracy

■ OUTPUT SIGNAL

Setpoint accuracy: ±0.2 % of the span

Temp. coefficient: ±0.015 %/°C (±0.008 %/°F)

Response time: Approx. 0.5 sec. (0 – 90 %)

Line voltage effect: Included in the setpoint accuracy

Insulation resistance: ≥ 100 MΩ with 500 V DC

Dielectric strength: 1500 V AC @1 minute (input to output

to power to ground)

STANDARDS & APPROVALS

EU conformity:

EMC Directive

EMI EN 61000-6-4

EMS EN 61000-6-2

Low Voltage Directive

EN 61010-1

Installation Category II

Pollution Degree 2

Input or output to power: Reinforced insulation (300 V)

Input to output: Basic insulation (300 V)

RoHS Directive
