MODEL: FRTS

FRTS SPECIFICATIONS

ES-1408 Rev.2 Page 3/4

http://www.m-system.co.jp/

EXTERNAL VIEW

Ratio Monitor (+)

Bias Monitor (+)

COM. (–)

Ratio Adj.

Bias Adj.

EXTERNAL DIMENSIONS unit: mm (inch)

1

2

3

4

7

6

8

5

26 (1.02)

15

(.59)

2–4.5 (.18)

HOLE

15 (.59) deep

8–M3.5

SCREW

7.8 (.31)

107 (4.21)

DIN RAIL

35mm wide

[3.3 (.13)]

CLAMP

(top & bottom)

137 (5.39)

•When mounting, no extra space is needed between units.

26 (1.02)

TERMINAL ASSIGNMENTS unit: mm (inch)

3

4

7

6

8

5

1

2

INPUT RESISTOR

(model: REM)

Input shunt resistor attached

for current input.
