MODEL: HPR

HPR SPECIFICATIONS

ES-3460 Rev.9 Page 3/4

http://www.m-system.co.jp/

EXTERNAL VIEW

Sensitivity Adj.

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

1

2

3

4

7

6

8

5

26 (1.02)

107 (4.21)

26 (1.02)

15

(.59)

2–4.5 (.18)

HOLE

15 (.59) deep

DIN RAIL

35mm wide

[3.3 (.13)]

8–M3.5

SCREW

CLAMP

(top & bottom)

137 (5.39)

•When mounting, no extra space is needed between units.

7.8 (.31)

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

Isolation

Base Socket

Pulse Volt.

Amplifier

Output

Driver

OUTPUT

4

5

6

POWER

7

8

INPUT

3

+

–

1

2

One-shot

+

■ Dry Contact

Input Connection Examples

–

■ Voltage Pulse

+

–

■ Open Collector

Output Connection Examples

+

–

5

6

+

–

■ Voltage Pulse

+

–

5

6

+

–

■ Relay Contact

•AC Powered

5

6

LOAD

Relay or

Counter Coil

Varistor or Spark

Quenching CIrcuit

•DC Powered

5

6

LOAD

Relay or

Counter Coil

Spark Quenching

Diode

Scaler

SENSITIVITY

ADJ.

4kΩ

+7.5V

+

–

1

2

+

–

1

2

+

–

U
