MODEL: FUD

FUD SPECIFICATIONS

ES-1446 Rev.7 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS unit: mm (inch)

1

2

3

4

7

6

8

5

26 (1.02)

15

(.59)

2–4.5 (.18)

HOLE

15 (.59) deep

8–M3.5

SCREW

7.8 (.31)

107 (4.21)

DIN RAIL

35mm wide

[3.3 (.13)]

CLAMP

(top & bottom)

137 (5.39)

•When mounting, no extra space is needed between units.

26 (1.02)

TERMINAL ASSIGNMENTS unit: mm (inch)

3

4

7

6

8

5

1

2

INPUT RESISTOR

(model: REM)

Input shunt resistor attached

for current input.

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

+

–

*

Base Socket

S

Z

*Input shunt resistor attached for current input.

INPUT

1

Low Drift

Amplifier

Reverser

Output

Driver

OUTPUT

R

2

3

4

5

6

U(+)

V(–)

POWER

7

8

Specifications are subject to change without notice.
