ADL5920ACPZ-R7 데이터시트(PDF) 4 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADL5920ACPZ-R7 데이터시트(HTML) 4 Page - Analog Devices |
|
|
4 / 26 page  ADL5920 Data Sheet Rev. B | Page 4 of 26 Parameter1 Test Conditions/Comments Min Typ Max Unit 1 GHz VRMSF, VRMSR, VTADJI = 0 V, VTADJS = 0 V Insertion Loss 1.1 dB Return Loss (RFIN, RFOUT) 50 Ω load on RFOUT 22 dB VSWR (RFIN, RFOUT) 1.16:1 Directivity 0.1 µF capacitors on CHPR+/CHPR− and CHPF+/CHPF− 20 dB Output Third-Order Intercept (IP3) 27 dBm per tone at RFIN, RFOUT terminated with 50 Ω, 1 MHz tone spacing 70.5 dBm ±1.0 dB Input Range VRMSF, VRMSR, CW input 49 dB Maximum Input Level, ±1.0 dB Slope and intercept calculated using linear regression from +30 dBm to −15 dBm 30 dBm Minimum Input Level, ±1.0 dB −19 dBm Deviation vs. Temperature Deviation from output at TA = 25°C −40°C, PIN = −10 dBm −0.41 dB −40°C, PIN = 20 dBm −0.32 dB 85°C, PIN = −10 dBm −0.5 dB 85°C, PIN = 20 dBm −0.11 dB 70°C, PIN = −10 dBm −0.24 dB 70°C, PIN = 20 dBm 0.15 dB Logarithmic Slope VRMSF, VRMSR 61 mV/dB Logarithmic Intercept VRMSF, VRMSR −27 dBm 2 GHz VRMSF, VRMSR, VTADJI = 0 V, VTADJS = 0.2 V Insertion Loss 1.3 dB Return Loss (RFIN, RFOUT) 50 Ω load on RFOUT 17 dB VSWR (RFIN, RFOUT) 1.30:1 Directivity No capacitors on CHPR+/CHPR− and CHPF+/CHPF− 16 dB ±1.0 dB Input Range VRMSF, VRMSR, CW input 45 dB Maximum Input Level, ±1.0 dB Slope and intercept calculated using linear regression from +30 dBm to −15 dBm 28 dBm Minimum Input Level, ±1.0 dB −17 dBm Deviation vs. Temperature Deviation from output at TA = 25°C −40°C, PIN = −10 dBm −0.44 dB −40°C, PIN = 20 dBm −0.73 dB 85°C, PIN = −10 dBm −0.98 dB 85°C, PIN = 20 dBm −0.58 dB 70°C, PIN = −10 dBm −0.36 dB 70°C, PIN = 20 dBm 0.04 dB Logarithmic Slope VRMSF, VRMSR 60.6 mV/dB Logarithmic Intercept VRMSF, VRMSR −26 dBm 3 GHz VRMSF, VRMSR, VTADJI = 0 V, VTADJS = 0.2 V Insertion Loss 1.5 dB Return Loss (RFIN, RFOUT) 50 Ω load on RFOUT 14 dB VSWR (RFIN, RFOUT) 1.5:1 Directivity No capacitors on CHPR+/CHPR− and CHPF+/CHPF− 13 dB ±1.0 dB Input Range VRMSF, VRMSR, CW input 43 dB Maximum Input Level, ±1.0 dB Slope and intercept calculated using linear regression from +30 dBm to −15 dBm 26 dBm Minimum Input Level, ±1.0 dB −17 dBm |
|
|
