MODEL: M2RS1

M2RS1 SPECIFICATIONS

ES-5127 Rev.5 Page 3/3

http://www.m-system.co.jp/

STANDARDS & APPROVALS

EU conformity:

EMC Directive

EMI EN 61000-6-4

EMS EN 61000-6-2

Low Voltage Directive

EN 61010-1

Installation Category II

Pollution Degree 2

Input or output to power: Reinforced insulation (300 V)

Input to output: Basic insulation (300 V)

RoHS Directive

EN 50581

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

5

9

21.5 (.85)

84 (3.31)

10 (.39)

15 (.59)

6 (.23)

DIN RAIL

35mm wide

[4 (.16)]

8–M3

SCREW

23 (.91)

2–4.2x5

(.17x.20)

MTG HOLE

6 (.24) deep

114 (4.49)

• When mounting, no extra space is needed between units.

4

8

12

14 13

1

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

1

4

A

B

B

RTD

5

8

+

–

Isolation

Base Socket

S

Z

Output

Driver

OUTPUT

9

12

Burnout

Linearizer

Differential

Amplifier

+

–

Reference

Resistor

Constant

Current

Constant

Current

U(+)

V(–)

POWER

13

14

Specifications are subject to change without notice.
