MODEL: M6SBS
M6SBS SPECIFICATIONS
ES-7985 Rev.10 Page 3/5
http://www.m-system.co.jp/
EXTERNAL DIMENSIONS unit: mm (inch)
49 (1.93)
37 (1.46)
11.5 (.45)
22.5 (.89)
116 (4.57)
27 (1.06)
72 (2.83)
37 (1.46)
3 (.12)
24.4 (.96)
22.5 (.89)
116 (4.57)
27 (1.06)
■ M6SBS-08, M6SBS-08P
■ M6SBS-08A
[5 (.20)]
[5 (.20)]
DIN RAIL
35mm wide
DIN RAIL
35mm wide
3–4.5 (.18) dia. MTG HOLE
2 (.08) deep
[3 (.12)]
[3 (.12)]
3–4.5 (.18) dia. MTG HOLE
2 (.08) deep
