MODEL: M8XV2

M8XV2 SPECIFICATIONS

ES-5469 Rev.8 Page 1/4

http://www.m-system.co.jp/

Dual Output Super-mini Signal Conditioners Pico-M Series

SIGNAL CONVERTER

(PC programmable)

Functions & Features

• Converts a DC input into two isolated process signals

• PC programmable

• Space-saving, easy-to-maintain, multi-channel installation

base

MODEL: M8XV2-[1][2]-R[3]

ORDERING INFORMATION

• Code number: M8XV2-[1][2]-R[3]

Specify a code from below for each of [1] through [3].

(e.g. M8XV2-S2V2V2-R/Q)

• Input range (e.g. 0 – 5 V DC)

• Output 1 / Output 2 (e.g. 1 – 5 V / 1 – 5 V DC)

If no specifications are specified, model M8XV2-S2V2V2-R/Q

will be shipped.

[S2: 1 - 5 V DC, V2V2: 1 - 5 V DC / 1 - 5 V DC]

• Use Ordering Information Sheet (No. ESU-5469) to specify

linearization data when the I/O signals are nonlinear. Linear

data will be programmed if not otherwise specified.

• Specify the specification for option code /Q

(e.g. /C01)

[1] INPUT

Current

Z1: Range 0 – 50 mA DC (Input resistance 25 Ω)

Voltage

S1: Range -1 – +1 V DC (Input resistance 1 MΩ min.)

S2: Range -10 – +10 V DC (Input resistance 1 MΩ min.)

(Configurator software is used to change input over the

described range of the selected suffix code.

For changing between suffix codes, set the Input Range

Selector on the side of unit before software adjustment.)

[2] OUTPUT 1 / OUTPUT 2

V2Z1: Range -10 – +10 V DC / Range 0 – 20 mA DC

V2V2: Range -10 – +10 V DC / Range -10 – +10 V DC

(Configurator software is used to change output over the

described range of the selected suffix code.

For changing between suffix codes, set the Output Range

Selector on the side of unit before software adjustment.)

POWER INPUT

DC Power

R: 24 V DC

(Operational voltage range 24 V ±10 %, ripple 10 %p-p max.)

[3] OPTIONS

blank: none

/Q: With options (specify the specification)

SPECIFICATIONS OF OPTION: Q

COATING (For the detail, refer to M-System's web site.)

/C01: Silicone coating

/C02: Polyurethane coating

/C03: Rubber coating

RELATED PRODUCTS

• Installation Base or Single Mount Base Socket (model:

M8BSx)

This unit must be mounted on dedicated base or socket.

• PC configurator software (model: JXCON)

Downloadable at M-System’s web site.

A dedicated cable is required to connect the module to the

PC. Please refer to the internet software download site or

the users manual for the PC configurator for applicable

cable types.

GENERAL SPECIFICATIONS

Construction: Plug-in

Mounting screw: M3 screw (torque 0.3 N·m)

Housing material: Flame-resistant resin (black)

Power supply: Via the Installation Base terminals

(model: M8BSx)

Isolation: Input to output 1 to output 2 to power

Overrange output: Approx. -15 to +115 %

Manual zero adjustments: -5 to +5 %

(factory setting: 0 %)

Manual span adjustments: 95 to 105 %

(factory setting: 100 %)

Programming: Downloaded from PC; input range, output

range, zero and span, simulating output, lineraization, etc.

Status indicator LED: Blinking patterns indicate different

operating status of the transmitter.

Configurator connection: 2.5 dia. miniature jack;

RS-232-C level
