MODEL: M60SVS

M60SVS SPECIFICATIONS

ES-8022 Rev.1 Page 3/3

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

DIN rail

(35mm wide)

102 (4.02)

0.5 (.02)

(Test lead pin 1 dia.)

•

With the end cover attached

•

Capable of High-density mounting

1

2

3

4

5

6

7

8

6 (.24)

2 (.08)

6 (.24)

3.7 (.15)

2.1 (.08)

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

S

Z

INPUT

Low Drift

Amplifier

3

4

POWER

OUTPUT

POWER

DIP SW for setting

various functions

DIP SW for setting

output range

Output

Driver

*

* Input shunt resistor incorporated for current input.

Isolation

Power LED

5

6

+

−

7

8

+

−

+

−

1

2

Specifications are subject to change without notice.
