MODEL: M2BD

M2BD SPECIFICATIONS

ES-5002 Rev.10 Page 3/7

http://www.m-system.co.jp/

COMM. MODULE FRONT PANEL

PWR

MS

NS

NA1

NA0

NA2

NA3

NA4

NA5

DR0

DR1

ON

Node

Address

Setting

Baud Rate

Setting

NS Indicator LED

Euro Type Connector Terminal

for DeviceNet

MS Indicator LED

Power LED

PU-2x Modular Jack

Refer to the instruction manual for detailed procedures.

EXTERNAL DIMENSIONS unit: mm (inch)

■ M2BD-041 (INPUT BASE)

1

2

3

4

5 8

1 4

5 8

1 4

5 8

1 4

5 8

1 4

FG1

13 14

CH4

CH1

6 (.24)

170 (6.69)

190 (7.48)

210 (8.27)

2–M3 POWER

TERMINALS

CT PROTECTOR (CTM2)

**

16–M3 INPUT TERMINALS

* 165 (6.50) required for pneumatic tubing for M2PV.

** Attached to M2CA and M2CE.
