MODEL: 10BXA
http://www.m-system.co.jp/
10BXA SPECIFICATIONS
ES-0892 Rev.9 Page 2/3
MOUNTING REQUIREMENTS
Observe appropriate wiring space over and under the rack.
450 (17.72)
4–M5 SCREW
465 (18.31)
ANGLE BRACKET
CONNECTION DIAGRAM
POWER
3
2
1
SUPPLY
PRESSURE
FG
+
–
DIMENSIONS unit: mm (inch)
465 (18.31)
480 (18.90)
435 (17.13)
1
2
3
4
5
6
7
8
9
10 11 12 13 14 15 16
SUPPLY CONNECTION
Rc 3/8”
3–M4 POWER
TERMINAL
1
2
3
