ME2-O2-

Ф20 electrochemical sensor detect gas concentration by measuring current based on the

electrochemical principle, which utilizes the electrochemical oxidation process of target gas on the

working electrode inside the electrolytic cell, the current produced in electrochemical reaction of the

target gas are in direct proportion with its concentration while following Faraday law, then concentration

of the gas could be get by measuring value of current.

1. Features

* Low consumption

* High precision

* High sensitivity

* Wide linear range

* Good anti-interference ability

* Excellent repeatability and stability

2. Application

Detecting O2 in mine, industry and environmental protection field.

3. Technical Parameter

4. External dimension

Item

Parameter

Detection gas

O2

Measurement Range

0～25%Vol

Max detecting

concentration

30%Vol

Sensitivity

（0.1~0.3）mA (In air)

≤15S

Load resistance

（recommended）

10k

Ω

Repeatability

＜2﹪output value

Stability（／month）

＜2﹪

Zero drift（-20℃ ～40℃ ）

≤0.1%vol

Storage temperature

-20℃ ～50℃

Storage Humidity

0﹪～99﹪RH

Pressure range

normal atmosphere±10%

Anticipated using life

2 years
