Surface light

SBAL-C6-A-R

Part number: 8031159

Data sheet

Feature

Value

Type code

SBAL-C6-A

Wavelength

620 nm

CE marking (see declaration of conformity)

As per EU EMC directive

Certification

RCM compliance mark

Working distance

100 - 300 mm

Lighting type

Surface light

Type of light

Red

LED

Clear

Electrical connection

12-pin

2x M12

Plug

Trigger level

Level 10 V ... UB

Nominal operating voltage DC

24 V

Permissible voltage fluctuations

+/- 10 %

Residual ripple

10 %

Current consumption during continuous operation

80 mA

Current consumption during flash operation

250 mA

Maximum number of devices connectable in series (diagram)

4

Reverse polarity protection

for all electrical connections

Ambient temperature during continuous operation

0 °C ... 50 °C

Ambient temperature during flash operation

0 °C ... 50 °C

Storage temperature

-20 °C ... 60 °C

Degree of protection

IP67

Product weight

60 g

Type of mounting

Clamped in dovetail slot

With accessories

Housing material

ABS-reinforced

Note on materials

RoHS-compliant

6/7/21 - Subject to change - Festo AG & Co. KG
