MODEL: 47NLNT

47NLNT SPECIFICATIONS

ES-9564 Rev.4 Page 2/5

https://www.m-system.co.jp/

INPUT SPECIFICATIONS

■ DC Current

Current range: Approx. 3.7 to 23 mA DC

Voltage drop: Approx. 6.3 V with 4 mA; approx. 6.5 V with

20 mA (Equivalent input impedance: Approx. 325 Ω)

(There is voltage drop generated by using the unit. For the

two-wire transmitter power supply, make sure that the

operable voltage for the two-wire transmitter is ensured

including the voltage drop by other devices and wiring

resistance.)

INSTALLATION

Operating temperature: -10 to +55°C (14 to 131°F)

Operating humidity: 10 to 90 %RH (non-condensing)

Mounting: Screw mounting

Weight: 115 g (0.25 lb)

PERFORMANCE

Accuracy

Display: ±0.1 % ± 1 digit

Temp. coefficient: ±0.015 %/°C (±0.008 %/°F)

STANDARDS & APPROVALS

EU conformity:

EMC Directive

EMI EN 61000-6-4

EMS EN 61000-6-2

RoHS Directive
