MODEL: 61C

61C SPECIFICATIONS

ES-6627 Rev.8 Page 2/4

http://www.m-system.co.jp/

SD indicator: Red LED turns on when transmitting.

RD indicator: Red LED turns on when receiving.

INPUT SPECIFICATIONS

■ Analog Input

Input range: 1 – 5 V DC

Input resistance: ≥ 1 MΩ

(Each input must be isolated by signal conditioners. Non-

isolated modules such as M2BW and M8BW are not usable.)

A/D conversion

Moving averaging: 4 samples

Sampling rate: 160 ms

A/D conversion output: Signed binary

Signal range 0 – 100 % is converted into hexadecimal 0000

– 2710 (0 – 10000). -15 to 0 % is a negative range

represented by 2's complements.

Overall range is represented by hexadecimal FA24 – 2CEC

(-1500 – +11500), for -15 – +115 %.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

RWr n+0

SIGN

BIT

INPUT 1 A/D CONVERSION DATA

RWr n+1

SIGN

BIT

INPUT 2 A/D CONVERSION DATA

RWr n+2

SIGN

BIT

INPUT 3 A/D CONVERSION DATA

RWr n+3

SIGN

BIT

INPUT 4 A/D CONVERSION DATA

RWr n+7

SIGN

BIT

INPUT 8 A/D CONVERSION DATA

RWr n+11

SIGN

BIT

INPUT 12 A/D CONVERSION DATA

RWr n+15

SIGN

BIT

INPUT 16 A/D CONVERSION DATA

RWr n+0 through RWr n+3 for 4 inputs.

RWr n+0 through RWr n+7 for 8 inputs or inputs of 16-input/output.

RWr n+0 through RWr n+15 for 16 inputs.

s A/D CONVERSION DATA

OUTPUT SPECIFICATIONS

■ Analog Output

Output range: 1 – 5 V DC

Load resistance: 20 kΩ minimum

(Output must be isolated with signal conditioners.

When the transmission line is open, the last value sampled

before failure is held. Non-isolated modules such as M2BW

and M8BW are not usable. )

D/A conversion input: Signed binary

Signal range 0 – 100 % is converted into hexadecimal

0000 – 2710 (0 – 10000).

-15 to 0 % is a negative range represented by 2's

complements.

Overall range is represented by hexadecimal FA24 – 2CEC

(-1500 – +11500), for -15 – +115 %.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

RWw n+0

SIGN

BIT

OUTPUT 1 D/A CONVERSION DATA

RWw n+1

SIGN

BIT

OUTPUT 2 D/A CONVERSION DATA

RWw n+2

SIGN

BIT

OUTPUT 3 D/A CONVERSION DATA

RWw n+3

SIGN

BIT

OUTPUT 4 D/A CONVERSION DATA

RWw n+7

SIGN

BIT

OUTPUT 8 D/A CONVERSION DATA

RWw n+11

SIGN

BIT

OUTPUT 12 D/A CONVERSION DATA

RWw n+15

SIGN

BIT

OUTPUT 16 D/A CONVERSION DATA

RWw n+0 through RWw n+3 for 4 outputs.

RWw n+0 through RWw n+7 for 8 outputs or outputs of 16-input/output.

RWw n+0 through RWw n+15 for 16 outputs.

s D/A CONVERSION DATA

INSTALLATION

Power consumption

•AC: Approx. 4 VA

•DC: Approx. 4 W (160 mA)

Operating temperature: -5 to +55°C (23 to 131°F)

Operating humidity: 30 to 90 %RH (non-condensing)

Atmosphere: No corrosive gas or heavy dust

Mounting: Installation Base (model: MxBS2)

Weight: 250 g (0.55 lb)

PERFORMANCE in percentage of span

A/D conversion: ±0.1 %

D/A conversion: ±0.1 %

Temp. coefficient: ±0.015 %/°C (±0.008 %/°F)

Permissible power failure duration: ≤ 10 msec.

Insulation resistance: ≥ 100 MΩ with 500 V DC

Dielectric strength: 1500 V AC @ 1 minute

(I/O to CC-Link to power)
