ATG-1133-R 데이터시트(PDF) 3 Page - M-System Co.,Ltd.

부품명 ATG-1133-R
상세설명  Limit Alarms (potentiometer adj.) A-UNIT
PDF  4 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  MSYSTEM [M-System Co.,Ltd.]
홈페이지  https://www.m-system.co.jp/
Logo MSYSTEM - M-System Co.,Ltd.

ATG-1133-R 데이터시트(HTML) 3 Page - M-System Co.,Ltd.

  ATG-1133-R Datasheet HTML 1Page - M-System Co.,Ltd. ATG-1133-R Datasheet HTML 2Page - M-System Co.,Ltd. ATG-1133-R Datasheet HTML 3Page - M-System Co.,Ltd. ATG-1133-R Datasheet HTML 4Page - M-System Co.,Ltd.
Zoom Inzoom in Zoom Outzoom out
 3 / 4 page
background image
MODEL: B3FP
B3FP SPECIFICATIONS
ES-7516 Rev.9 Page 3/4
https://www.m-system.co.jp/
EXTERNAL VIEW
10 11 12
4
5
6
Zero Adj.
Span Adj.
n FRONT VIEW
n SIDE VIEW
1
SW4
SW3
2 3 4 5 6 7 8
SW2
SW1
Configuration DIP SW
Configuration Rotary SW
High-order Digit (0 – 9)
Low-order Digit (0 – 9)
0
9
1
EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm [inch]
10 11 12
4
5
6
18 (.71)
110.5 (4.35)
[5 (.20)]
DIN RAIL
35mm wide
• When mounting, no extra space is needed between units.
