MODEL: B3FP
B3FP SPECIFICATIONS
ES-7516 Rev.9 Page 3/4
https://www.m-system.co.jp/
EXTERNAL VIEW
10 11 12
4
5
6
Zero Adj.
Span Adj.
n FRONT VIEW
n SIDE VIEW
1
SW4
SW3
2 3 4 5 6 7 8
SW2
SW1
Configuration DIP SW
Configuration Rotary SW
High-order Digit (0 – 9)
Low-order Digit (0 – 9)
0
9
1
EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm [inch]
10 11 12
4
5
6
18 (.71)
110.5 (4.35)
[5 (.20)]
DIN RAIL
35mm wide
• When mounting, no extra space is needed between units.
