Operator unit

CDSA-D3-RV

Part number: 8126915

Data sheet

Feature

Value

Type code

CDSA

No. of function keys

20

Number of system LEDs

5

Display

LCD display

With backlighting

Display properties

Touchscreen

Display size

7"

Control elements

Touch sensitive keyboard

Release control unit

Emergency-off pushbutton

Input current

<= 5.6 A

DC operating voltage range

19.2 V ... 30 V

Display resolution

WSVGA, 600 x 1024 pixels

Certification

CCC

RCM compliance mark

c UL us - Listed (OL)

KC characters

KC EMC

CE marking (see declaration of conformity)

As per EU EMC directive

As per EU RoHS directive

Certificate issuing authority

UL E239998

Storage temperature

-20 °C ... 70 °C

Relative air humidity

5 - 95 %

Degree of protection

IP65

Note on degree of protection

When USB cover flap is closed

In mounted state

Protection class

III

Ambient temperature

0 °C ... 40 °C

Product weight

950 g

Electrical power consumption

12 W

IP address allocation

DHCP

FCT

Nominal operating voltage DC

24 V

Power failure buffering

10 ms

Nominal altitude of use above sea level

<= 2000 m NHN

Power supply, function

Release control

Emergency off

Power supply

Power supply, type of connection

Socket strip

6/15/21 - Subject to change - Festo AG & Co. KG

1/2
