Data Sheet

ADRF5025

Rev. B | Page 3 of 13

SPECIFICATIONS

ELECTRICAL SPECIFICATIONS

VDD = 3.3 V, VSS = −3.3 V, VCTL = 0 V or 3.3 V, and case temperature (TCASE) = 25°C for a 50 Ω system, unless otherwise noted.

Table 1.

Parameter

Symbol

Test Conditions/Comments

Min

Typ

Max

Unit

FREQUENCY RANGE

0.009

44,000

MHz

INSERTION LOSS

Between RFC and RF1/RF2 (On)

With Impedance Match

See Figure 24

9 kHz to 18 GHz

0.9

18 GHz to 26 GHz

1.2

26 GHz to 35 GHz

1.3

35 GHz to 40 GHz

1.4

40 GHz to 44 GHz

1.6

Without Impedance Match

See Figure 25

9 kHz to 18 GHz

0.9

18 GHz to 26 GHz

1.0

26 GHz to 35 GHz

1.4

35 GHz to 40 GHz

1.7

40 GHz to 44 GHz

2.2

RETURN LOSS

RFC and RF1/RF2 (On)

With Impedance Match

See Figure 24

9 kHz to 18 GHz

18 GHz to 26 GHz

26 GHz to 35 GHz

35 GHz to 40 GHz

40 GHz to 44 GHz

Without Impedance Match

See Figure 25

9 kHz to 18 GHz

18 GHz to 26 GHz

26 GHz to 35 GHz

35 GHz to 40 GHz

40 GHz to 44 GHz

ISOLATION

Between RFC and RF1/RF2

9 kHz to 18 GHz

18 GHz to 26 GHz

26 GHz to 35 GHz

35 GHz to 40 GHz

40 GHz to 44 GHz

Between RF1 and RF2

9 kHz to 18 GHz

18 GHz to 26 GHz

26 GHz to 35 GHz

35 GHz to 40 GHz

40 GHz to 44 GHz

SWITCHING CHARACTERISTICS

Rise and Fall Time

tRISE, tFALL

10% to 90% of RF output

0.6

µs

On and Off Time

tON, tOFF

50% VCTL to 90% of RF output

1.7

µs

RF Settling Time

0.1 dB

50% VCTL to 0.1 dB of final RF output

3.4

µs

0.05 dB

50% VCTL to 0.05 dB of final RF output

4.2

µs
