38 / 40 page  ADRF6750 Rev. A | Page 38 of 40 BILL OF MATERIALS Table 25. Bill of Materials Qty Reference Designator Description Manufacturer Part Number 1 DUT ADRF6750 LFCSP, 56-lead 8 mm × 8 mm Analog Devices ADRF6750ACPZ 1 Y2 VCO, 10 MHz Jauch O 10.0-VX3Y-T1 1 SPI Connector, 9-pin, D-sub plug, SDEX9PNTD ITW McMurdo FEC 150750 1 CONN Connector, I2C, SEMCONN receptacle Molex 15830064 2 C1, C21 Capacitor, 10 μF, 25 V, tantalum, TAJ-C AVX FEC 197518 13 C2, C4, C6, C8, C10, C12, C14, C16, C18, C19, C48, C53, C55 Capacitor, 10 pF, 50 V, ceramic, C0G, 0402 Murata FEC 8819564 15 C3, C5, C7, C9, C11, C13, C15, C17, C22, C47, C49 to C52, C54 Capacitor, 100 nF, 25 V, X7R, ceramic, 0603 AVX FEC 317287 1 C20 Capacitor, 220 μF, 6.3 V, tantalum, Case Size C AVX FEC 197087 4 C30 to C33 Capacitor spacing, 0402 (do not install) 1 C26 Capacitor, 1 nF, 50 V, XR7, ceramic, 0603 Murata FEC 722170 1 C24 Capacitor, 47 nF, 50 V, Xr7, ceramic, 1206 Murata FEC 1740542 2 C23, C25 Capacitor, 680 pF, 50 V, NPO, ceramic, 0603 Murata FEC 430997 4 C38, C39 Capacitor, 1 nF, 50 V, C0G, ceramic, 0402 Murata FEC 8819556 4 C40, C44, C46, C57 Capacitor, 100 pF, 50 V, C0G, ceramic, 0402 Murata FEC 8819572 12 J1 to J5, J7, J10 to J12, J14, J15, TXDIS SMA end launch connector Johnson/Emerson 142-0701-851 3 J18, J20, J21 Jumper, 3-pin + shunt Harwin FEC 148533 and FEC 150411 4 L1, L2 Inductor, 20 nH, 0402, LQW series Murata LQW15AN20N 4 L3, L4 Inductor, 10 μH, 0805, LQM series Murata LQM21FN1N100M 4 R2 to R5 Resistor spacing, 0603 (user-defined values) 5 R6 to R9, R36 Resistor, 0 Ω, 1/16 W, 1%, 0402 Vishay Draloric FEC 1158241 2 R10, R11 Resistor, 0402, spacing (do not install) 1 R13 Resistor, 4.7 kΩ, 1/10 W, 1%, 0603 Bourns CR0603-FX-472 2 R14, R39 Resistor, 1.2 kΩ, 1/10 W, 5%, 0603 Yageo FEC 9233393 2 R12, R16 Resistor, 270 Ω, 1/16 W, 1%, 0603 Multicomp FEC 9330917 1 R15 Resistor, 300 Ω, 1/16 W, 1%, 0603 Multicomp FEC 93330968 2 R17, R18 Resistor, 0603, spacing (do not install) 3 R35, R44, R45 Resistor, 51 Ω, 1/16 W, 5%, 0402 Bourns CR0402-JW-510 4 R48 to R51 Resistor, 330 Ω, 1/10 W, 5%, 0805 Bourns CR0805-JW-331 3 R59 to R61 Resistor, 100 Ω, 1/10 W, 5%, 0805 Bourns CR0805-JW-101 |
|
