ADRF6780ACPZN-R2 데이터시트(PDF) 5 Page - Analog Devices

부품명 ADRF6780ACPZN-R2
상세설명  5.9 GHz to 23.6 GHz, Wideband, Microwave Upconverter
PDF  35 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  AD [Analog Devices]
홈페이지  http://www.analog.com
Logo AD - Analog Devices

ADRF6780ACPZN-R2 데이터시트(HTML) 5 Page - Analog Devices

  ADRF6780ACPZN-R2 Datasheet HTML 1Page - Analog Devices ADRF6780ACPZN-R2 Datasheet HTML 2Page - Analog Devices ADRF6780ACPZN-R2 Datasheet HTML 3Page - Analog Devices ADRF6780ACPZN-R2 Datasheet HTML 4Page - Analog Devices ADRF6780ACPZN-R2 Datasheet HTML 5Page - Analog Devices ADRF6780ACPZN-R2 Datasheet HTML 6Page - Analog Devices ADRF6780ACPZN-R2 Datasheet HTML 7Page - Analog Devices ADRF6780ACPZN-R2 Datasheet HTML 8Page - Analog Devices ADRF6780ACPZN-R2 Datasheet HTML 9Page - Analog Devices Next Button
Zoom Inzoom in Zoom Outzoom out
 5 / 35 page
background image
Data Sheet
ADRF6780
Rev. D | Page 5 of 35
Parameter
Test Conditions/Comments
Min
Typ
Max
Unit
LOGIC OUTPUTS
Output High Voltage Range, VOH
VP18 − 0.4
1.8
V
Output Low Voltage Range, VOL
0
0.4
V
Output High Current, IOH
500
µA
POWER INTERFACE
VPBB, VPLO, VPBI
3.15
3.3
3.45
V
VPBB, VPLO, VPBI Supply Current
×1 LO path enabled, IF path disabled
340
mA
×2 LO path enabled, IF path disabled
390
mA
×1 LO path enabled, IF path enabled
490
mA
×2 LO path enabled, IF path enabled
540
mA
VP18
1.7
1.8
1.9
V
VP18 Supply Current
1
mA
VPDT, VPRF
4.75
5
5.25
V
VPDT, VPRF Supply Current
×1/×2 LO path enabled, IF path disabled
180
mA
×1/×2 LO path enabled, IF path enabled
160
mA
Total Power Consumption
×2 LO path enabled, IF path enabled
2.58
W
Power down
35
50
mW
