background image
Data Sheet
HMC129ALC4
Rev. 0 | Page 3 of 16
SPECIFICATIONS
TA = 25°C, IF = 100 MHz, LO = 15 dBm, upper side band. All measurements performed as a downconverter, unless otherwise noted, on the
evaluation printed circuit board (PCB).
Table 1.
Parameter
Min
Typ
Max
Unit
FREQUENCY
RF Pin
4
8
GHz
IF Pin
DC
3
GHz
LO Pin
4
8
GHz
LO DRIVE LEVEL
9
15
18
dBm
RADIO FREQUENCY (RF) PERFORMANCE
Downconverter
Conversion Loss
7
9
dB
Single Sideband (SSB) Noise Figure
7
dB
Input Third-Order Intercept (IIP3)
15
17
dBm
Input 1 dB Compression Point (IP1dB)
10
dBm
Input Second-Order Intercept (IIP2)
50
dBm
RF to IF Isolation
20
dB
LO to RF Isolation
40
dB
LO to IF Isolation
35
40
dB
Upconverter
Conversion Loss
7
dB
Input Third-Order Intercept (IIP3)
17
dBm
Input 1 dB Compression Point (IP1dB)
7
dBm
