MODEL: M1EXR-2

M1EXR-2 SPECIFICATIONS

ES-5984 Rev.2 Page 5/8

https://www.m-system.co.jp/

PARAMETER LIST

It is available to con gure or con rm settings shown below by using front button. Con guring or con rming with PC is

available when using M1E con gurator software (model: M1ECFG).

MODE

ITEM

SETTING PARAMETER

RANGE

UNIT

INITIAL VALUE

Ch1 setting

01

Lockout setting

Lock / Unlock

—

Lock

09

Ch1 Temperature unit

°C / °F / K

—

°C

11

Ch1 Input range

JPt 100 (JIS ’89)

Pt 100 (JIS ’89)

Pt 100 (JIS ’97, IEC)

Pt 50 Ω (JIS ’81)

Ni 508.4 Ω

Pt 1000

Ni 100

Cu 10 @ 25°C

—

Pt 100 (JIS ’97, IEC)

12

Ch1 0 % input setting

JPt 100 (JIS ’89) : -200.00 – 480.00

Pt 100 (JIS ’89) : -200.00 – 630.00

Pt 100 (JIS ’97, IEC) : -200.00 – 830.00

Pt 50 Ω (JIS ’81) : -200.00 – 629.00

Ni 508.4 Ω : -50.00 – 180.00

Pt 1000 : -200.00 – 830.00

Ni 100 : -50.00 – 180.00

Cu 10 @ 25°C : -50.00 – 230.00

°C

0.0

13

Ch1 100 % input setting

JPt 100 (JIS ’89) : -180.00 – 500.00

Pt 100 (JIS ’89) : -180.00 – 650.00

Pt 100 (JIS ’97, IEC) : -180.00 – 850.00

Pt 50 Ω (JIS ’81) : -180.00 – 649.00

Ni 508.4 Ω : -30.00 – 200.00

Pt 1000 : -180.00 – 850.00

Ni 100 : -30.00 – 200.00

Cu 10 @ 25°C : -30.00 – 250.00

°C

100.0

16

Ch1 Input decimal point

No decimal point

The number of decimal places : 1 or 2

—

1 place of decimals

18

Ch1 Output range

0 – 20 mA

-5 – +5 V

-10 – +10 V

—

0 – 20 mA

19

Ch1 0 % output setting

0.000 – 19.000

-5.000 – 4.750

-10.000 – 9.000

mA

V

V

4.000

20

Ch1 100 % output setting

1.000 – 20.000

-4.750 – 5.000

-9.000 – 10.000

mA

V

V

20.000

74

Ch1 Burnout

None / Down / Up

—

Up

75

Ch1 Sensor wires

2 Wires / 3 Wires

—

3 Wires

76

Ch1 Wire resistance

0.000 – 50.000*

Ω

0.000

79

Ch1 Filter time constant

0 – 30

Sec.

0

80

Ch1 Input zero ne adjust

-10.00 – 10.00*

°C

0.00

81

Ch1 Input span ne adjust

-10.00 – 10.00*

°C

0.00

82

Ch1 Output zero ne adjust

-5.000 – 5.000

%

0.000

83

Ch1 Output span ne adjust

95.000 – 105.000

%

100.000

89

Ch1 Loop test

-10.00 – 110.00

%

Cancel
