MODEL: R3-AV8

R3-AV8 SPECIFICATIONS

ES-8436 Rev.7 Page 2/4

https://www.m-system.co.jp/

PERFORMANCE

Conversion accuracy: Refer to the table at the end of this

section.

Conversion rate: 160 / 80 / 40 / 20 msec. selectable

Data range: 0 – 10000 of the input range

Data allocation: 4

Current consumption: 100 mA

Temp. coefficient: ±0.015 % /°C (±0.008 %/°F)

(±0.03 % /°C [±0.02 %/°F] with 0 – 5 V or 1 – 5 V range)

Insulation resistance: ≥ 100 MΩ with 500 V DC

Dielectric strength: 1000 V AC @ 1 minute (input 1 to input

2 to input 3 to input 4 to input 5 to input 6 to input 7 to

input 8 to internal bus or internal power)

2000 V AC @ 1 minute (power input to FG; isolated on the

power supply module)

Conversion accuracy

RANGE

RATE

160 msec.

80 msec.

40 msec.

20 msec.

All ranges

±0.1%

±0.2%

±0.4%

±0.8%

STANDARDS & APPROVALS

EU conformity:

EMC Directive

EMI EN 61000-6-4

EMS EN 61000-6-2

RoHS Directive

ALARM SETTING

The following parameters are programmable using the PC

Configurator Software (model: R3CON).

■ALARM TRIP POINT (-15.00 to +115.00 %;

factory set to A1: 80.00, A2: 60.00, A3: 40.00, A4: 20.00)

Four alarm setpoints are selectable per each input.

■ALARM TYPE

(High or Low; factory set to A1: High, A2: High, A3: Low,

A4: Low)

High or Low alarm is selectable for each alarm trip point.

High alarm: An alarm is set when the input signal goes

above the setpoint.

Low alarm: An alarm is set when the input signal goes below

the setpoint.

■DEADBAND (HYSTERESIS)

(0.00 to 100.00 %; factory set to 5.00)

Deadband (deviation between the points where the alarm is

set and reset) is selectable for each alarm trip point.

■ALARM ON DELAY TIME

(0.0 to 99.0 seconds; factory set to 1.0)

The alarm output is set when the preset time elapses after

the input has entered in the alarm range.

This setting is common to all 8 points.

■POWER ON DELAY TIME

(0.0 to 99.0 seconds; factory set to 5.0)

The alarm output start functioning in the preset time after

the power has been turned on.

This setting is common to all 8 points.

■ALARM HOLD TIME

(0.0 to 99.0 seconds; factory set to 1.0)

The alarm output is held for the preset time even if it is

reset in shorter time.

This setting is common to all 8 points.
