MODEL: R7FN-RS4

R7FN-RS4 SPECIFICATIONS

ES-7808-C Rev.0 Page 5/6

http://www.m-system.co.jp/

I/O DATA DESCRIPTIONS

0

15

• Di

■ ANALOG INPUT

CH0

Unused

Unused

Unused

Unused

CH1

CH2

CH3

ADD.n

ADD.n+1

ADD.n+2

ADD.n+3

The data is 16-bit binary.

Negative value is represented in 2’s complements.

0

15

0

15

0

15

0

15

• Do

0

15

0

15

0

15

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

4

5

6

7

1

2

3

10 11 12 13

2

3

4

1

15 16 17 18

7

8

9

6

14

5

30 (1.18)

[5 (.20)]

DIN RAIL

35mm wide

54 (2.13)

17 (.66)

115 (4.53)

7–M3 SCREW

TERMINALS

for FLEX NETWORK, POWER

18–M3 SCREW

TERMINALS

for INPUT

6 (.24)

6 (.24)
