Data Sheet
ADCA3270
Rev. 0 | Page 5 of 14
ABSOLUTE MAXIMUM RATINGS
Table 4.
Parameter
Rating
VCC
DC Supply over Voltage (5 minute)
30 V
RF Input Voltage (RFINPUT), Single Tone
75 dBmV
Temperature
Operating Range, TPADDLE
−30°C to +110°C
Peak Reflow (Moisture Sensitivity Level
(MSL) 3
260°C
Junction (TJ) to Maintain 1 Million Hour
Mean Time to Failure (MTTF)
170°C
Nominal Junction (TJ)
TPADDLE = 110°C, ICC = 480 mA, VCC = 24 V
144°C
Storage (TS) Range
−40°C to +150°C
Stresses at or above those listed under Absolute Maximum
Ratings may cause permanent damage to the product. This is a
stress rating only; functional operation of the product at these
or any other conditions above those indicated in the operational
section of this specification is not implied. Operation beyond
the maximum operating conditions for extended periods may
affect product reliability.
THERMAL RESISTANCE
Thermal performance is directly linked to printed circuit board
(PCB) design and operating environment. Careful attention to
PCB thermal design is required.
θJC is the thermal resistance from the operating portion of the
PHEMT device to the outside surface of the package closest to
the device mounting area (the exposed paddle on the bottom of
the case). See the Thermal Considerations section for additional
information.
Table 5. Thermal Resistance
Package Type
θJC1
Unit
CE-9-2
2.9
°C/W
1
Thermal resistance (θJC) is defined as between the TPADDLE and the internal
device junction (TJ).
ELECTROSTATIC DISCHARGE (ESD) RATINGS
The following ESD information is provided for handling of
ESD-sensitive devices in an ESD protected area only.
Human body model (HBM) per ANSI/ESDA/JEDEC JS-001.
ESD Ratings for ADCA3270
Table 6. ADCA3270, 6-Terminal LGA_CAV
ESD Model
Withstand Threshold (V)
Class
HBM
500
Class 1B, passed
ESD CAUTION
