MODEL: R8-NEIP1

R8-NEIP1 SPECIFICATIONS

ES-9799 Rev.0 Page 2/5

http://www.m-system.co.jp/

1.6 A)

Internal power supply (power supply for I/O module):

• DC power supply: 5 V DC

• Current capacity: 1.6 A

Excitation supply output (excitation for I/O module)

•DC: 24 V DC ±10 %

•Operational current: 10 A

(From power supply (exitation supply) connector, via

connector for internal bus, supplied to each I/O module.

Power output current consumption must be under

operational current.)

Operating temperature: -10 to +55°C (14 to 131°F)

Operating humidity: 30 to 90 %RH (non-condensing)

Atmosphere: No corrosive gas or heavy dust

Mounting: DIN rail

Weight: 180 g (0.40 lb)

PERFORMANCE

Insulation resistance: ≥ 100 MΩ with 500 V DC

Dielectric strength: 500 V AC @ 1 minute

(EthrtNet/IP to internal bus or internal power or power input

to excitation supply to FE1)

STANDARDS & APPROVALS

EU conformity:

EMC Directive

EMI EN 61000-6-4

EMS EN 61000-6-2

RoHS Directive
