Heavy-duty incremental encoder

E N I 1 1 H D - R

- xxxx

- T

Connection type

Junction box with ...

C1 Cable, 1 m

C2 Cable, 2 m

C5 Cable, 5 m

CA Cable, 10 m

AA M23 device plug, cw

AB M23 device plug, ccw

TC Cable duct

Connection alignment

T Tangential

Interface, electric

PP5 Push-pull, 6-wire, increased EMC

Pulses/pulse counts per revolution

xxxx

xxxx = 0100, 0360, 0500, 0512, 0600, 1000, 1024, 1250, 2048,

2500

(more on request)

Degree of protection

E IP66/IP67

9

IP69K

Flange

NA Support plate 70 mm, straight

NB Support plate 120 mm, straight

NC Support plate 120 mm, right angle

T1 Support plate 70 mm, straight, with articulated arm 70 mm

T2 Support plate 120 mm, straight, with articulated arm 70 mm

T3 Support plate 120 mm, right angle, with articulated arm 70 mm

V1 Support plate 70 mm, straight, with articulated arm 120 mm

V2 Support plate 120 mm, straight, with articulated arm 120 mm

V3 Support plate 120 mm, right angle, with articulated arm 120 mm

Shaft diameter

16 16 mm

20 20 mm

T1 17 mm cone

R1 16 mm, dielectrically strong

R3 20 mm, dielectrically strong

R2 17 mm cone, dielectrically strong

Shaft type

R Recessed hollow shaft

Version

HD Heavy duty

Size

11 Housing diameter: 110 mm

Device type

ENI Incremental rotary encoder
