Incremental rotary encoder

EN I 5 8 I L - R

-

-

Connection type

B2

Fixed cable with M12 plug,

8-pin, 1 m

B4

Fixed cable with M12 plug,

5-pin, 1 m

C1

Cable, 1 m

C2

Cable, 2 m

C5

Cable, 5 m

CA

Cable, 10 m

AA

M23 device plug,

clockwise (type 9416)

AB

M23 device plug,

counterclockwise

(type 9416L)

BE

M12 device plug,

8-pin (type V19)

BD

M12 device plug, 5-pin

(type V15)

MA

MIL7 connector

(Typ 9415)

MB

MIL10 connector

(Typ 9419)

Connection alignment

Aaxial

Rradial

Electrical interface

UD1 Universal output driver, UB 5 V ... 30 V

Pulse count

0100, 0120, 0125, 0200, 0256, 0360, 0500, 1000, 1024, 1250, 1500,

1800, 2000, 2048, 2500, 3600, 4000, 4096, 5000

Degree of protection

5IP65

7IP67

Flange

BA

Spring plate, single long

JA

Spring plate, single short

DA

Dual spring plate

Shaft diameter

08 8 mm

10 10 mm

12 12 mm

14 14 mm

15 15 mm

U2 1/4 inch

U3 3/8 inch

U4 1/2 inch

Shaft type

R Recessed hollow shaft

Version

IL Industrial Line

Size

58 Housing diameter 58 mm

Device type

ENI Incremental rotary encoder

Note: Preferred options are in bold letters.
