2 / 4 page ![]() PLL601-02 Low Phase Noise PLL Clock Multiplier 47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/03/04 Page 2 PIN DESCRIPTIONS Name Number Type Description CLK 1 O Clock output from VCO. Equals the input frequency times multiplier. REFEN 2 I Reference clock enable. When Low, it disables REFOUT. When High, it enables REFOUT. VDD 3,4,5 P Power Supply. XOUT 6 O Crystal Connection. S1 7 I Multiplier Select Pin 1. Determines CLK output. Has internal pull-up. XIN 8 I Crystal input to be connected to 10-27MHz fundamental parallel mode crys- tal (CL=15pF). On chip load capacitors: No external capacitor required. GND 9,14,15,16 P Ground. S3 10 I Multiplier Select Pin 3. Determines CLK output. Has internal pull-up. S0 11 I Multiplier Select Pin 0. Determines CLK output. Has internal pull-up. OE 12 I Output Enable. Tri-state CLK and REFOUT when low. Has internal pull-up. REFOUT 13 O Buffered crystal oscillator clock output. Controlled by REFEN. ELECTRICAL SPECIFICATIONS 1. Absolute Maximum Ratings PARAMETERS SYMBOL MIN. MAX. UNITS Supply Voltage VDD 4.6 V Input Voltage, dc VI -0.5 VDD+0.5 V Output Voltage, dc VO -0.5 VDD+0.5 V Storage Temperature TS -65 150 °C Ambient Operating Temperature* TA -40 85 °C Junction Temperature TJ 125 °C Lead Temperature (soldering, 10s) 260 °C ESD Protection, Human Body Model 2 kV Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other con- ditions above the operational limits noted in this specification is not implied. * Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only. 2. AC Specifications PARAMETERS CONDITIONS MIN. TYP. MAX. UNITS Input Frequency 10 27 MHz Output Frequency At 3.3V 160 MHz Output Rise Time 0.8V to 2.0V with no load 1.5 ns Output Fall Time 2.0V to 0.8V with no load 1.5 ns Duty Cycle @ 50% VDD 45 50 55 % |
|
|
