PLL702-01

Clock Generator for PowerPC Based Applications

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991

www.phaselink.com

Rev 07/18/05 Page 7

3. DC Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

VDD_ANA

VDD_DIG

Nominal voltage is 3.3V

2.97

3.63

V

Nominal voltage is 2.5V

2.25

2.75

V

Operating Voltage

VDD_USB

VDD_PCI

VDD_ASIC1

VDD_ASIC2

VDD_CPU

Nominal voltage is 3.3V

2.97

3.63

V

Input High Voltage

VDD/2

V

Input Low Voltage

VDD/2

VDD/2 - 1

V

Input High Voltage

For all Tri-level input

VDD-0.5

V

Input Low Voltage

For all Tri-level input

0.5

V

Input High Voltage

For all normal input

2

V

Input Low Voltage

For all normal input

0.8

V

Output High Voltage

VDD = 3.3V

2.4

V

Output Low Voltage

0.4

V

Output High Voltage At

CMOS Level

VDD-0.4

V

Nominal Output Current

25

mA

Operating Supply Current

No Load

35

mA

Short-circuit Current

±100

mA

4. Crystal Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Crystal Resonator Frequency

Parallel Fundamental Mode

14.31818

MHz

Crystal Loading Rating

21

pF

Recommended ESR

AT cut

30

Ω

Note: A detailed crystal specification document is also available for this part.
