PLL602-20

200MHz XO IC With Selectable 4X/8X Multiplier

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 02/18/05 Page 4

DC SPECIFICATIONS

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Supply Current, Dynamic, with

Loaded Outputs

At 80MHz, load=15pF,

VDD=3.3V

15

mA

Operating Voltage

2.25

3.63

V

Output Low Voltage

0.4

V

Output High Voltage

V

Output Current

24

mA

Short-circuit Current

±50

mA

JITTER AND PHASE NOISE SPECIFICATION

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

at 155MHz, with capacitive decoupling

between VDD and GND.

50

Period Jitter

(PkPk – 10,000 samples)

at 80MHz, with capacitive decoupling

between VDD and GND.

55

ps

Phase Noise relative to carrier

125MHz @100Hz offset

-100

dBc/Hz

Phase Noise relative to carrier

125MHz @1kHz offset

-118

dBc/Hz

Phase Noise relative to carrier

125MHz @10kHz offset

-112

dBc/Hz

Phase Noise relative to carrier

125MHz @100kHz offset

-98

dBc/Hz

Phase Noise relative to carrier

125MHz @1MHz offset

-107

dBc/Hz
