background image
ADL6316
Data Sheet
Rev. 0 | Page 20 of 37
Table 19. Internal Temperature Measurement from ADC Conversion
Address
Setting
Description
0x000
0x18
Make SDO active
0x100
0xFF
Enable ADC
0x127
0x20
Enable ADC clock divider and set ADC clock frequency
0x120
0x00
PTAT to ADC input, PTAT on mux output
0x00A
0xCC
Register dummy write
0x00A
0xCC
Register dummy write
0x00A
0xCC
Register dummy write
0x00A
0xCC
Register dummy write
0x00A
0xCC
Register dummy write
0x129
Not applicable
Read temperature from ADC
