6 Configuration and Dimensions:

7 Electrical Characteristics:

Inductance

Test Freq.

RDC

Isat

Tolerance

Marking

(uH )

(Ω)Max.

(A)

(±%)

SCD03021T-R82□-N

0.82

7.96 MHz,1 V

0.06

2.2

SCD03021T-1R0□-N

7.96 MHz,1 V

0.07

2.08

SCD03021T-1R2□-N

1.2

7.96 MHz,1 V

0.08

SCD03021T-1R4□-N

1.4

7.96 MHz,1 V

0.09

1.86

SCD03021T-1R5□-N

1.5

7.96 MHz,1 V

0.11

1.8

SCD03021T-1R8□-N

1.8

7.96 MHz,1 V

0.11

1.8

SCD03021T-2R2□-N

2.2

7.96 MHz,1 V

0.13

1.39

SCD03021T-2R7□-N

2.7

7.96 MHz,1 V

0.14

1.32

SCD03021T-3R3□-N

3.3

7.96 MHz,1 V

0.17

1.25

10,20

SCD03021T-3R9□-N

3.9

7.96 MHz,1 V

0.19

1.2

SCD03021T-4R7□-N

4.7

7.96 MHz,1 V

0.21

1.13

SCD03021T-5R6□-N

5.6

7.96 MHz,1 V

0.22

0.91

SCD03021T-6R8□-N

6.8

7.96 MHz,1 V

0.25

0.85

SCD03021T-7R0□-N

7.96 MHz,1 V

0.28

0.82

SCD03021T-8R2□-N

8.2

7.96 MHz,1 V

0.28

0.82

SCD03021T-100□-N

2.52 MHz,1 V

0.32

0.74

10,20

SCD03021T-120□-N

2.52 MHz,1 V

0.35

0.64

SCD03021T-150□-N

2.52 MHz,1 V

0.4

0.6

SCD03021T-180□-N

2.52 MHz,1 V

0.48

0.54

SCD03021T-220□-N

2.52 MHz,1 V

0.58

0.5

10,20

SCD03021T-270□-N

2.52 MHz,1 V

0.65

0.43

SCD03021T-330□-N

2.52 MHz,1 V

0.8

0.4

SCD03021T-390□-N

2.52 MHz,1 V

0.9

0.37

SCD03021T-470□-N

2.52 MHz,1 V

1.19

0.36

SCD03021T-500□-N

2.52 MHz,1 V

1.22

0.33

NOTE: □-tolerance K=±10% / M=±20%

1.Operating temperature range

－４０℃ ~ １０５℃(Including self - temperature rise)

2.Isat for Inductance drop 10% from its value without current.

"-N" FOR COMPLETELY LEAD FREE TYPE(INCLUDING FERRITE BODY & SOLDER)

Part No.

SCD03021T-470M-N

01.08.2021
