Data Sheet
ADP5041
Rev. B | Page 21 of 40
200
0
3.8
4.3
4.8
5.3
INPUT VOLTAGE (V)
20
40
60
80
100
120
140
160
180
0.000001A
0.0001A
0.001A
0.01A
0.1A
0.15A
0.3A
Figure 75. LDO1, LDO2 Ground Current vs. Input Voltage, Across Output
Load (A), VOUT = 3.3 V
CH2
CH3
A CH3
27.2mA
2
VOUT
30.0mV/DIV
80.0mA/DIV
B
W 20.0M
3
1MΩ BW 20.0M
200µs/DIV
5.0MS/s
200ns/pt
IOUT
Figure 76. LDO1, LDO2 Response to Load Transient, IOUT from 1 mA to
80 mA, VOUT = 4.7 V
CH2
CH3
A CH3
27.2mA
2
VOUT
30.0mV/DIV
80.0mA/DIV
B
W 20.0M
3
1MΩ BW 20.0M
200µs/DIV
5.0MS/s
200ns/pt
IOUT
Figure 77. LDO1, LDO2 Response to Load Transient, IOUT from 10 mA to
200 mA, VOUT = 4.7 V
CH2
CH3
A CH3
42.0mA
2
VOUT
30.0mV/DIV
50.0mA/DIV
B
W 20.0M
3
1MΩ BW 120M
200µs/DIV
500kS/s
2.0µs/pt
IOUT
Figure 78. LDO1, LDO2 Response to Load Transient, IOUT from 1 mA to
80 mA, VOUT = 3.3 V
CH2
CH3
A CH3
89.6mA
2
VOUT
50.0mV/DIV
80.0mA/DIV
B
W 20.0M
3
1MΩ BW 120M
200µs/DIV
500kS/s
2.0µs/pt
IOUT
Figure 79. LDO1, LDO2 Response to Load Transient, IOUT from 10 mA to
200 mA, VOUT = 3.3 V
CH2
CH3
A CH3
89.6mA
2
VOUT
30.0mV/DIV
80.0mA/DIV
B
W 20.0M
3
1MΩ BW 120M
200µs/DIV
500kS/s
2.0µs/pt
IOUT
Figure 80. LDO1, LDO2 Response to Load Transient, IOUT from 1 mA to
80 mA, VOUT = 1.8 V
