E5EC-800
21
Isolation/Insulation Block Diagrams
Models with 2 Auxiliary Outputs
Nomenclature
Communications and event inputs
Sensor input and CT input
Voltage output (for driving SSR) and current output
Relay output
Auxiliary output 1
Auxiliary output 2
: Reinforced insulation
: Functional isolation
Power
Supply
E5EC
Top View
Temperature unit
Operation indicators
Shift (PF) key
No.1 display
No. 2 display
No. 3 display
Down key
Up key
Mode key
Level key
