Vesper Technologies Inc - Preliminary Version

The VM1010’s Wake on Sound mode brings voice activation to battery-powered

consumer devices — while drawing nearly zero power, making it ideal for voice-

interface devices such as smart speakers, TV remotes, smart earbuds, and smart

home products.

The VM1010 has a small 3.76 mm X 2.95 mm X 1.3 mm package and is reflow

solder-compatible with no sensitivity degradation. It operates in environmentally

harsh surroundings because it is dust- and moisture-resistant.

Specifications

All specifications are at 25°C, VDD = 1.8 V unless otherwise noted. Valid for Date

Code 1811 and higher.

Parameter

Symbol

Conditions

Min.

Typ.

Max.

Units

Normal Mode Acoustic Specifications

Sensitivity

1 kHz, 94 dB

SPL

-41

-38

-35

dBV

Signal-to-Noise

Ratio

SNR

94 dB SPL at 1

kHz signal

dB(A)

20 Hz – 20

kHz, A-

weighted

Noise

Signal-to Noise

Ratio Voice

Band

SNR

94 dB SPL at 1

kHz signal

dB(A)

20 Hz – 8 kHz,

A-weighted

Total Harmonic

Distortion

THD

94 dB SPL

0.1

Acoustic

Overload Point

AOP

10.0% THD

125

dB SPL
