background image
2SA733
Low Frequency Amplifier
PNP Epitaxial Silicon Transistor
Document No.: F51936S
27-NOV-2021 V 2.0
www.futurewafer.com.tw
FQE-001-04
1/7
1. Synopsis
1-1. Feature List
●
BV CEO: -50V (Min.)
●
Low Saturation Voltage V CE(sat) < -0.3V @ -0.1A
●
I C = -100mA Continuous Collector Current
●
Complementary to 2SC945
1-2. Mechanical Characteristics
●
Molded JEDEC Package: TO-92
●
Packing: Tape Box
●
Flammability rating UL 94V-0
●
Halogen Free
●
JEDEC MSL Classification: LEVEL 1
1-3. Device Characteristics
1-4. Classification of h FE
B
C
E
Device Symbol
C
B
E
TO-92
