2SC945
Low Frequency Amplifier
NPN Epitaxial Silicon Transistor
Document No.: F51939M
27-NOV-2021 V 2.0
www.futurewafer.com.tw
FQE-001-04
4/7
3-2. Ratings and Characteristics Curve-Fig 3~6 (@TA = 25°C, Unless Otherwise Specified)
I C, Collector Current (mA)
Fig 5. Saturation Voltage
Fig 6. Collect Current vs. V BE
V BE, Base-Emitter Voltage (V)
Fig 3. Collector Output Capacitance
V CB, Collector-Base Voltage (V)
V BE, Base-Emitter Voltage (V)
Fig 4. Base-Emitter On Voltage
