SCALE 1 : 1

10.20

0.402

0.50

0.020

WASHER

19.00

0.748

10.60

0.417

2.10

0.083

6.30

0.248

5.00

0.197

2.70

0.106

6.00

0.236

1/4"-36UNS-2A

THREADS

HEX 11.00

0.433

12.70

0.500

FLAT

5.80

0.228

9.10

0.358

1.40

0.055

6.30

0.248

O-RING

20.00

0.787

6.44

0.254

2.48

0.098

SUPPORT

HEAT

SHRINK

SPACER

SOCKET

BODY

EXPLODED VIEW

SCALE 2 : 1

1.24

0.049

9.00

0.354

0.50

0.020

0.60

0.024

SOCKET

0.2x2x2

GROOVE

HEX 8.0

1.60

0.063

NUT

NOTES: (UNLESS OTHERWISE SPECIFIED)

1. ALL DIMENSIONS ARE IN mm [INCHES].

2. DIMENSIONS APPLY AFTER FINISHING.

3. MANUFACTURE TO BE COMPLIANT WITH EU RoHS DIRECTIVE,

USE MATERIALS THAT DO NOT CONTAIN REACH SUBSTANCES

OF VERY HIGH CONCERN >1000ppm, AND USE DRC

CONFLICT-FREE SOURCED MATERIALS.

4. SAFETY BREAK ALL SHARP CORNERS AND EDGES 0.5 MAXIMUM.

5 SEE TABLE I FOR ELECTRICAL SPECIFICATIONS. (SHEET 2)

6 SEE TABLE II FOR ENVIRONMENTAL SPECIFICATIONS. (SHEET 2)

7 SEE TABLE III FOR MECHANICAL SPECIFICATIONS. (SHEET 2)

8. SEE PARTSLIST. "*" INDICATES FINISH TYPE.

FILE://M:\Linx\Web\Website Content\Diagrams\Current on site\consma014-r178.pdf

REVISIONS

REV

DESCRIPTION

DATE

APPV

A INITIAL RELEASE OF LINX INTERNAL DRAWING

01/MAR/19

CLL

SHEET 1 OF 2

LDCFDAL_C

SCALE: 3:1

A

TITLE:

SIZE DWG. NO.

REV

DO NOT SCALE DRAWING

CONSMA014-R178-*

A

SMA FEMALE BULKHEAD MOUNT CABLE

END CRIMP WITH O-RING FOR RG-178 CABLE

159 ORT LANE

MERLIN, OR 97532

ANGLES: 1

DRAWN: M. SCHULTE

ENGR: D. VARATHARAJAN

DT: 21/JAN/19

DT: 08/MAR/19

MATERIAL:

FINISH:

PROJECTION:

THAT IS THE SOLE PROPERTY OF LINX TECHNOLOGIES, AND SHALL BE

TREATED AS SUCH. NO DISCLOSURE OR REPRODUCTION OF THIS

DOCUMENT IS PERMITTED, IN WHOLE OR IN PART, WITHOUT THE

EXPRESS WRITTEN PERMISSION OF LINX TECHNOLOGIES OR ITS

DESIGNATED AGENTS.

TOLERANCES:

0.50 [.020]-5.00 [.200]= 0.20 [.008]

5.00 [.200]-30.00 [1.200]= 0.40 [.016]

30.0 [1.20]-120.0 [4.75]= 0.60 [0.24]

120.0 [4.75]-315.0 [12.40]= 1.0 [.040]
