AiT Semiconductor Inc.

www.ait-ic.com

2SD1007

GENERAL PURPOSE TRANSISTORS

NPN TRANSISTORS

REV1.1

- MAR 2015 RELEASED, AUG 2020 UPDATED -

- 1 -

DESCRIPTION

FEATURES

The 2SD1007 is available in SOT-89 package



High collector emitter voltage: VCEO>120V



Available in SOT-89 package

PIN DESCRIPTION

1. BASE

2. COLLECTOR

3. EMITTER

ORDERING INFORMATION

Package Type

Part Number

SOT-89

SPQ: 1,000/Reel

2SD1007-R

2SD1007-Q

2SD1007-P

hFE

2SD1007-R = 90~180

2SD1007-Q = 135~270

2SD1007-P = 200~400

AiT provides all RoHS Compliant Products
