Product data sheet
Connections and Schema
TM5SDO2S
Electronic Module 2DO 240 Vac Triac 1 A 3 Wires
Wiring Diagram
1
Internal electronics
2
24 Vdc I/O power segment integrated into the bus bases
3
External power supply 100...240 Vac
4
External fuse type T slow-blow 3.15 A - 250 V
5
Inductive load protection
6
2-wire load
7
3-wire load
Apr 6, 2022
