Data Sheet
ADL5387
Rev. C | Page 7 of 27
TYPICAL PERFORMANCE CHARACTERISTICS
VS = 5 V, TA = 25°C, LO drive level = 0 dBm, RBIAS = open, unless otherwise noted.
20
15
10
5
0
0
200
400
600
800 1000 1200 1400 1600 1800 2000
RF FREQUENCY (MHz)
GAIN
INPUT P1dB
TA = +85°C
TA = +25°C
TA = –40°C
Figure 3. Conversion Gain and Input 1 dB Compression Point (IP1dB) vs.
RF Frequency
0
5
10
15
20
20
30
40
50
60
70
80
90
100 110
120 130
FREQUENCY (MHz)
INPUT P1dB
GAIN
TA = +85°C
TA = +25°C
TA = –40°C
Figure 4. Conversion Gain and Input 1 dB Compression Point (IP1dB) vs.
RF Frequency (Low Frequency Range)
80
70
50
30
60
40
20
10
0
200
400
600
800 1000 1200 1400 1600 1800 2000
RF FREQUENCY (MHz)
TA = –40°C
TA = +25°C
TA = +85°C
Q CHANNEL
I CHANNEL
INPUT IP3
(I AND Q CHANNELS)
INPUT IP2
Figure 5. Input Third-Order Intercept (IIP3) and
Input Second-Order Intercept Point (IIP2) vs. RF Frequency
10
20
30
40
50
60
70
80
20
30
40
50
60
70
80
90
100 110 120 130
FREQUENCY (MHz)
IIP2
IIP3
TA = –40°C
TA = +25°C
TA = +85°C
Figure 6. Input Third-Order Intercept (IIP3) and Input Second-Order Intercept
Point (IIP2) vs. RF Frequency (Low Frequency Range)
2.0
1.5
1.0
0.5
0
–0.5
–1.0
–1.5
–2.0
0
200
400
600
800 1000 1200 1400 1600 1800 2000
RF FREQUENCY (MHz)
TA = +85°C
TA = +25°C
TA = –40°C
Figure 7. I/Q Gain Mismatch vs. RF Frequency
–2.0
–1.5
–1.0
–0.5
0
0.5
1.0
1.5
2.0
20
30
40
50
60
70
80
90
100 110 120 130
FREQUENCY (MHz)
TA = –40°C
TA = +25°C
TA = +85°C
Figure 8. I/Q Gain Mismatch vs. RF Frequency (Low Frequency Range)
