22
© 2012 Littelfuse • Transportation Products Catalog Excerpt
www.littelfuse.com
Power Distribution Centers
STARTER TERMINALS
Description
The starter terminal series are cable lugs for heavy-duty
applications such as starter motors and battery connections.
Ratings
Part Number
mm2
Mounting Hole
Width (mm)
Material
Plating
Ref.
09130633LXN (50 pcs)
2.5-6.0
6.5 mm
11
Cu
Sn
2906
09130633Z (1250 pcs)
09130634LXN (50 pcs)
6.0-15
8.4 mm
15
Cu
Sn
2910
09130634Z (600 pcs)
09130635LXN (50 pcs)
10 -25
8.4 mm
15
Cu
Sn
2916
09130635Z (400 pcs)
09130636LXN (50 pcs)
16-35
10.5 mm
19
Cu
Sn
29025
09130636Z (200 pcs)
09130637LXN (50 pcs)
25-50
10.5 mm
19
Cu
Sn
29035
09130637Z (150 pcs)
09130638LXN (50 pcs)
35-70
10.5 mm
19
Cu
Sn
29050
09130638Z (100 pcs)
09130639LXN (50 pcs)
50-95
13.5 mm
22
Cu
Sn
29070
09130639Z (50 pcs)
09130640LXN (50 pcs)
16
6.4 mm
11
Cu
Sn
2916 HK
09130640Z (600 pcs)
09130641LXN (50 pcs)
25
8.4 mm
15
Cu
Sn
29025 HK
09130641Z (300 pcs)
09130642LXN (50 pcs)
35
8.4 mm
15
Cu
Sn
29035 HK (8.4)
09130642Z (200 pcs)
09130643LXN (50 pcs)
35
10.5 mm
19
Cu
Sn
29035 HK (10.5)
09130643Z (150 pcs)
09130644LXN (50 pcs)
50
8.4 mm
17
Cu
Sn
29050 HK (8.4)
09130644Z (100 pcs)
09130645LXN (50 pcs)
50
10.5 mm
19
Cu
Sn
29050 HK (10.5)
09130645Z (125 pcs)
09130646LXN (50 pcs)
70
10.5 mm
21
Cu
Sn
29070 HK
09130646Z (75 pcs)
