background image
Electrical Characteristics(TA=25°C unless otherwise specified)
Rev 2.0 :
www.leiditech.com
12.01.2019
2/4
Parameter
Symbol
Min
Typ
Max
Unit
Test Condition
Reverse Working Voltage
VRWM
18
V
Breakdown Voltage
VBR
19.5
V
IT = 1mA
Reverse Leakage Current
IR
0.2
µA
VRWM = 18V
Clamping Voltage
VC
40
V
IPP = 2A (8 x 20 s pulse)
Junction Capacitance
CJ
0.3
pF
V = 0V, f = 1MHz
μ
R
ULC1811CDN
