Product data sheet

Specifications

NEMA Motor Starter, Type S,

nonreversing, Size 1P, 36A, 5 HP

at 230 VAC, 5 kA SCCR, 1 phase,

2 pole, melting alloy, 120 VAC coil,

open

8536SCO2V02S

Product availability : Stock - Normally stocked in distribution

facility

Price* : 662.00 USD

Main

Product Type

Motor starter

Product Range

S

Starter Type

Non reversing

Complementary

NEMA Size

1P

Rated Current

36 A

Number of Poles

2P

Maximum Voltage Rating

600 V AC

Phase

1 phase

Type of Overload

Melting alloy 2

Horsepower Rating

5 HP 230 V AC

3 HP 115 V AC

SCCR

Circuit-breaker: 5 kA at 600 V AC

Fuse: 5 kA at 600 V AC

Coil Voltage

110 V AC 50 Hz

120 V AC 60 Hz

Control Circuit Type

Separate control circuit

Control Units

No control units

Pilot Light

Without pilot light

Auxiliary Contacts

Without

Terminal Type

Screw clamp terminals

Height

6.81 in (172.96 mm)

Width

3.50 in (88.90 mm)

Depth

4.22 in (107.19 mm)

Environment

Enclosure Type

Not rated (open device)

*  Price is “List Price” and may be subject to a trade discount – check with your local distributor or retailer for actual price.

Jul 4, 2022
